Design & Technology: EU

Assemble in China

Without computer

Capacity : 500kg

Also you can work as per all International standard like ISO, AATCC, ASTM, GB, BS-EN, AS.

Technical Parameter

1. Measuring force range: 1%～100% of full scale: 5000N
2. Minimum scale value: 0.01N Force measurement accuracy: ≤±0.2%F·S
3. Stretching speed: (0.01～1000)mm/min digital speed regulation, error ≤±1%
4. The maximum stroke of the instrument: 600mm
5. Elongation resolution: 0.01mm
6. Specimen clamping: pneumatic clamping or manual clamping
7. Power supply: AC220V±10% 50Hz 600W
8. Dimensions: (550×530×1400)mm (host L×W×H)
9. Weight: 74kg (standard configuration)
10. Sampling frequency: 2000Hz

Including:

Equipped with air compressor/1 pcs of pneumatic gripper

Load Cell of

100N&500N&2000N&2500N&5000N

Software of functions as per Fabric, Buttons

& Zipper tests.
